Algemeen |
Processormodel |
Intel Core i7 (12. Gen.) 12700 / 25 MB Intel Smart Cache, max. Turbo-Frequency 4.9 GHz) |
Besturingssysteem |
Windows 11 Home |
|
Software |
Voorgeïnstalleerde software |
1 maand gratis testversie voor nieuwe Microsoft® 365 klanten |
|
Processor |
Processorfamilie |
Core i7 |
Aantal processorkernen |
12-Core |
Processor socket |
FCLGA1700 Socket |
|
Geheugen |
Intern geheugen |
16 GB |
Geheugenlayout |
2 x 8 GB |
Maximum intern geheugen |
128 GB |
Kloksnelheid geheugen |
3200 MHz |
Intern geheugentype |
DDR4 SDRAM |
Geheugenslots |
4 stuk(s) |
Geheugen form factor |
DIMM, 288-PIN |
|
Opslagmedia |
Totale opslagcapaciteit |
1 TB |
HDD interface |
4x SATA 6Gb/s
2x M.2 Socket 3, M key, Type 2260/2280 PCIe 4.0 x4/x2 SSD support |
Soorten RAID |
Supports SATA RAID 0/1/5/10 |
Aantal storage drives geïnstalleerd |
1 |
SSD interfaces |
PCIe 4.0 |
SSD capaciteit |
1 GB |
HDD capaciteit |
1 x 1 TB - SSD |
Opslagmedia |
SSD M.2 |
|
Prestatie |
Markt positionering |
Gamer |
Type product |
Personal-Computer |
Geluidsniveau |
25.9 dB(A) in operation office mode without ODD |
Audio-uitgangskanalen |
8 kanalen |
Chipset moederbord |
Intel B660 |
Audiosysteem |
High Definition Audio |
|
Design |
Type behuizing |
Midtowermodel |
Certificering |
Assemblierung volgens ISO9001 in Duitsland
Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
Toetsenbord formaat |
Optioneel. Geen toetsenbord inbegrepen. |
|
Toetsenbord |
Taal toetsenbord |
optioneel |
Aansluiting |
USB |
|
Technische details |
Land |
International |
|
Inhoud van de verpakking |
Meegeleverde accessoires |
Quick Start Guide, voedingskabel EU, voedingskabel CH |
Taal toetsenbord |
Optioneel. Geen toetsenbord inbegrepen. |
|
Uitbreidingsmodules |
Uitbreidingsslots |
1x PCIe 4.0 x16, 2x PCIe 3.0 x1 |
|
Gewicht en omvang |
Hoogte |
47 cm |
Breedte |
21.7 cm |
Diepte |
49.6 cm |
Gewicht |
11.5 kg |
|
Overige specificaties |
Aantal drive bays |
2 intern - 8.9 cm ( 3.5/ 2.5 mit Adapter)
5 intern 6.4 cm (2.5 SSD) |
Interface |
2x USB 2.0, 1x PS/2, 1x D-Sub (VGA), 1x HDMI 2.1, 2x DisplayPort 1.2, 5x USB 3.2 Gen1 (2x voorzijde), 1x USB 3.2 Gen2 Type-C, 1x RJ-45, 3x Audio jacks
Optioneel: 1x COM, 1x LPT, 1x TPM header |
Compatibele besturingssystemen |
Windows 10, Windows 11 |
Merk moederbord |
Gigabyte B660M DS3H |
Type koeling |
TERRA Silent Heatpipe Cooler (CPU-koeler met RGB-verlichting optioneel verkrijgbaar, verschillend van productafbeelding) |
Speciale eigenschappen |
TPM 2.0
Secure Boot
2x USB 3.2 Gen1 Typ A + Audio voorzijde
Vooraf geïnstalleerde 120mm ventilator aan de achterzijde
3x Vooraf geïnstalleerde RGB 120mm ventilatoren aan de voorzijde
Mesh Front Panel
RGB LED Fans & Lightning Control
Tempered Glass Side Panel |
|
Muis |
Inclusief muis |
Razer Mouse Abyssus Essential |
|
Grafisch |
Geheugen ingebouwde grafische adapter |
12 GB GDDR6 |
Maximale resolutie ingebouwde grafische adapter |
Max. 7680 x 4320 |
Grafische adapter |
ASUS VGA 12GB RTX3060 DUAL-O12G-V2 |
Ingebouwde grafische adapter |
Plug in kaart - PCI Express |
Aantal displayports grafische adapter |
1x HDMI, 3x DP (Display Poort) |
|
Energie |
Stroombron |
ATX voeding met 80 Plus , geschikt voor standaard gebruik max. 60 uur/week
Efficiency : 85% |
Stroomverbruik (in standby) |
Ø 1.9 Watt (Sleep Mode S3, Suspend to RAM, WOL geactiveerd)
0,25 Watt Soft off (S5 Mode) |
Maximaal ingangsvermogen |
600 W |
Voeding |
Ø 39 Watt Long Idle-Mode
Ø 167 kWh per jaar (TEC = Typical Energy Consumption)
Voor verdere informatie ga je naar www.wortmann.de/green en/of in de Quicklinks van dit product (indien beschikbaar) |
AC-adapter ingangsspanning |
Wisselstroom 200/240 V (50 Hz) |
|
Eisen aan de omgeving |
Bedrijfstemperatuur (T-T) |
5 °C - 35 °C |
Aanbevolen relatieve luchtvochtigheid bij gebruik |
10-75% (niet condenserend ) |
|
Netwerk |
Ethernet LAN |
RJ45 |
LAN controller |
Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps, WOL/PXE |
Datalink-protocollen |
Ethernet
Fast Ethernet
Gigabit Ethernet |
|
Optische drive |
Soort optische drive |
DVD-brander |
|
Invoerapparaat |
Bewegingsdetectietechnologie |
Optical |
Aansluiting |
USB
Opmerking: Toetsenbord optioneel verkrijgbaar. |
