| Algemeen |
| Processormodel | Intel Core i5 (10. Gen.) 10400 / 2.9 GHz (12 MB SmartCache, tot 4.3 GHz met Intel Turbo Boost Technology) |
| Besturingssysteem | Windows 10 Pro Gratis update naar Windows 11 wanneer beschikbaar* |
| Software |
| Voorgeïnstalleerde software | 30 Dagen testversie voor Microsoft® 365 nieuwe klanten. |
| Processor |
| Processorfamilie | Core i5 |
| Aantal processorkernen | Hexa-Core |
| Processor socket | FCLGA1200 Socket |
| Geheugen |
| Intern geheugen | 8 GB |
| Geheugenlayout | 1 x 8 GB |
| Maximum intern geheugen | 64 GB |
| Kloksnelheid geheugen | 3200 MHz |
| Intern geheugentype | DDR4 SDRAM |
| Geheugenslots | 2 |
| Geheugen form factor | DIMM, 288-PIN |
| Opslagmedia |
| Totale opslagcapaciteit | 250 GB |
| HDD interface | 4x SATA 6Gb/s ports, 1x M.2 slot (Key M) (supports PCIe 3.0 x4) |
| Soorten RAID | Ondersteunt geen raid |
| SSD interfaces | PCIe (NVMe) |
| SSD capaciteit | 250 GB |
| HDD capaciteit | 1x 250 GB SSD |
| Opslagmedia | SSD M.2 |
| Prestatie |
| Markt positionering | Business - Slim Desktop |
| Type product | Personal-Computer |
| Geluidsniveau | 22,2 dB Idle-Mode |
| Audio-uitgangskanalen | 8 kanalen |
| Chipset moederbord | Intel H510 |
| Audiosysteem | High Definition Audio |
| Design |
| Type behuizing | Small Form Factor |
| Certificering | Assemblierung volgens ISO9001 in Duitsland Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Toetsenbord formaat | Optioneel. Geen toetsenbord inbegrepen. |
| Toetsenbord |
| Aansluiting | USB PS/2 |
| Technische details |
| Land | International |
| Inhoud van de verpakking |
| Meegeleverde accessoires | Quick Install Guide, voeding, kabel, 2-delige standvoet |
| Taal toetsenbord | Optioneel. Geen toetsenbord inbegrepen. |
| Uitbreidingsmodules |
| Uitbreidingsslots | 1x PCIe 4.0 (11th Gen) /3.0 (10th Gen) x16 slot, 2x PCIe 3.0 x1 slots Intel11th Gen processors ondersteund PCIe 4.0 x16- Intel® 10th Gen processors support PCIe 3.0 x16 |
| Gewicht en omvang |
| Hoogte | 9.5 cm |
| Breedte | 34.1 cm |
| Diepte | 38 cm |
| Gewicht | 6 kg |
| Overige specificaties |
| Aantal drive bays | 1 voor toegankelijk - 13.3 cm ( 5.25 Slim-Format ) 1 voor toegankelijk - 8.9 cm ( 3.5 Slim-Format ) 1 intern - 8.9 cm ( 3.5 ) 1 intern - 6,3 cm (2.5) voor SSD |
| Interface | 4x USB 3.2 Gen 1 ports (2x voorzijde), 4 x USB 2.0 ports (all Type-A) 1x DisplayPort, 1x D-Sub (VGA), 1x HDMI, 1x LAN RJ5, 3x Audio, 2x PS/2 Optioneel: 1x COM |
| Compatibele besturingssystemen | Windows 10, Windows 11 |
| Merk moederbord | Asus Prime H510M-A |
| Type koeling | TERRA Silent CPU ventilator (actief) |
| Speciale eigenschappen | Convertible Slim Desktop with lockable back-cover Horizontal and vertical use Optional: Standfoot for TFSs with VESA (75/ 100 mm) mount Notice: Only cards low profile format TPM 2.0 2x USB 3.2 Gen voorzijde TPM 2.0 Secure Boot Windows Autopilot ready |
| Muis |
| Inclusief muis | TERRA Wheel Mouse optical |
| Grafisch |
| Geheugen ingebouwde grafische adapter | Dynamisch |
| Maximale resolutie ingebouwde grafische adapter | HDMI 4096 x 2160 @ 60Hz (11th Gen CPU), 4096 x 2160 @ 24Hz (10th Gen CPU) DP 4096 x 2304 @60Hz VGA max. 1920x1200 |
| Grafische adapter | Intel UHD Graphics 630 (1100 MHz) |
| On-board graphics adapter model | Intel UHD Graphics 630 (1100 MHz) |
| Aantal displayports grafische adapter | 1x DP, 1x HDMI, 1x VGA ondersteund Dual-Display-Monitoring |
| Energie |
| Stroombron | TFX voeding met 80 Plus Bronze, geschikt voor standaard gebruik max. 60 uur/week |
| Stroomverbruik (in standby) | Ø 1.1 Watt (S3 Mode, Suspend to RAM, WOL geactiveerd) / 0,25 Watt soft off (S5 mode) |
| Maximaal ingangsvermogen | 300 Watt |
| Voeding | Ø 17 Watt Idle-Mode Ø 79 kWh per jaar (TEC = Typical Energy Consumption) |
| AC-adapter ingangsspanning | Wisselstroom 230 V ( 50Hz ) |
| Eisen aan de omgeving |
| Bedrijfstemperatuur (T-T) | 5 °C - 35 °C |
| Aanbevolen relatieve luchtvochtigheid bij gebruik | 10-75% (niet condenserend ) |
| Netwerk |
| Ethernet LAN | RJ45 |
| LAN controller | Intel I219V, WOL/PXE |
| Datalink-protocollen | Ethernet Fast Ethernet Gigabit Ethernet |
| Optische drive |
| Soort optische drive | DVD-brander |
| Invoerapparaat |
| Bewegingsdetectietechnologie | Optical |
| Aansluiting | USB Opmerking: Toetsenbord optioneel verkrijgbaar. |
| Opmerkingen |
| Aanvullende informatie | *Het upgradeproces bevindt zich in de afrondingsfase en gaat naar verwachting eind 2021 van start. De precieze procedure en het tijdschema kunnen variëren naargelang het toestel. |
